NKI40/30-TV-XL INA

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 55
3. Width (B) MM 30
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 2.1654
6. Width (B) Inch 1.1811
7. Width (b) mm 30

Suffix description

1. TV Polyamide Cage
2. XL X-Life

Technical details

1. Availability 128 pcs
2. Brand INA
3. Item number NKI40/30-TV-XL INA
4. Also known as 0507622810000
   NKI40/30-TV

5. EAN 4012802323245
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.216

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 103000
2. Radial Dynamic Load Rating Cr (N) 52000
3. Limiting speed (n G) 10200
4. Reference speed (n ϑr) 5400
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NKI, light series
