NKI30/30-TV-XL INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 45
3. Width (B) MM 30
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.7717
6. Width (B) Inch 1.1811
7. Width (b) mm 30

Suffix description

1. TV Polyamide Cage
2. XL X-Life

Technical details

1. Availability 39 pcs
2. Brand INA
3. Item number NKI30/30-TV-XL INA
4. Also known as 0507621920000
   NKI30/30-TV

5. EAN 4012802701203
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.17

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 81000
2. Radial Dynamic Load Rating Cr (N) 46000
3. Limiting speed (n G) 12900
4. Reference speed (n ϑr) 6600
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NKI, light series
