NKI25/20-F-XL INA

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 38
3. Width (B) MM 20
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 1.4961
6. Width (B) Inch 0.7874
7. Width (b) mm 20

Suffix description

1. F Machined Window Type Steel Cage
2. XL X-Life

Technical details

1. Availability 23 pcs
2. Brand INA
3. Item number NKI25/20-F-XL INA
4. Also known as 0001973860000
   NA253820
   NBI253820
   NKI25/20
   NKJ25/20A
   TAFI253820

5. EAN 4012802059106
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.079

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 34000
2. Limiting speed (n G) 15300
3. Reference speed (n ϑr) 8500
4. ECLASS number 23-05-09-07
5. ECLASS2 number 23-05-09-07
