NKI15/20-XL INA

All dimensions

1. Inner (d) MM 15
2. Outer (D) MM 27
3. Width (B) MM 20
4. Inner (d) Inch 0.5906
5. Outer (D) Inch 1.063
6. Width (B) Inch 0.7874
7. Width (b) mm 20

Suffix description

1. XL X-Life

Technical details

1. Availability 93 pcs
2. Brand INA
3. Item number NKI15/20-XL INA
4. Also known as 0507619780000
   NA152720
   NBI152720
   NKI15/20
   NKJ15/20A
   TAFI152720

5. EAN 4012802734294
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.049

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 23600
2. Radial Dynamic Load Rating Cr (N) 18700
3. Limiting speed (n G) 21600
4. Reference speed (n ϑr) 12100
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NKI, light series
