NKI15/16-XL INA

All dimensions

1. Inner (d) MM 15
2. Outer (D) MM 27
3. Width (B) MM 16
4. Inner (d) Inch 0.5906
5. Outer (D) Inch 1.063
6. Width (B) Inch 0.6299
7. Width (b) mm 16

Suffix description

1. XL X-Life

Technical details

1. Availability 52 pcs
2. Brand INA
3. Item number NKI15/16-XL INA
4. Also known as 0507619600000
   NA152716
   NBI152716
   NKI15/16
   NKJ15/16A
   TAFI152716

5. EAN 4012802734263
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.039

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 17400
2. Radial Dynamic Load Rating Cr (N) 14700
3. Limiting speed (n G) 21600
4. Reference speed (n ϑr) 12400
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NKI, light series
