NKI100/40-XL-C3 INA

All dimensions

1. Inner (d) MM 100
2. Outer (D) MM 130
3. Width (B) MM 40
4. Inner (d) Inch 3.937
5. Outer (D) Inch 5.1181
6. Width (B) Inch 1.5748
7. Width (b) mm 40

Suffix description

1. XL X-Life
2. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number NKI100/40-XL-C3 INA
4. Also known as 0507629580030
   NA10013040C3
   NKI100/40-C3
   NKJ100/40A.C3
   TAFI10013040C3

5. EAN 4047643204125
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 1.33

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 290000
2. Limiting speed (n G) 4200
3. Reference speed (n ϑr) 2600
4. ECLASS number 23-05-09-07
5. ECLASS2 number 23-05-09-07
