NKI100/30-XL INA

All dimensions

1. Inner (d) MM 100,00
2. Outer (D) MM 130,00
3. Width (B) MM 30,00
4. Inner (d) Inch 3.9370
5. Outer (D) Inch 5.1181
6. Width (B) Inch 1.1811
7. Width (b) mm 30,00

Suffix description

1. XL X-Life

Technical details

1. Availability 38 pcs
2. Brand INA
3. Item number NKI100/30-XL INA
4. Also known as 0507629400000
   NA10013030
   NBI10013030
   NKI100/30
   NKJ100/30A
   TAFI10013030

5. EAN 4047643204156
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.99

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 210000
2. Radial Dynamic Load Rating Cr (N) 111000
3. Basic static load rating, radial (C 0r) "210000.0000"
4. Limiting speed (n G) "4200.0000"
5. Reference speed (n ϑr) "2650.0000"
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NKI, light series

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
