NK90/25-XL INA

All dimensions

1. Inner (d) MM 90,00
2. Outer (D) MM 110,00
3. Width (B) MM 25,00
4. Inner (d) Inch 3.5433
5. Outer (D) Inch 4.3307
6. Width (B) Inch 0.9843
7. Under roller diameter (F w) mm 90,00

Suffix description

1. XL X-Life

Technical details

1. Availability 111 pcs
2. Brand INA
3. Item number NK90/25-XL INA
4. Also known as 0507546960000
   NB9011025
   NK90/25
   RNA9011025
   TAF9011025

5. EAN 4012802058949
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.423

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 132000
2. Radial Dynamic Load Rating Cr (N) 81000
3. Basic static load rating, radial (C 0r) "132000.0000"
4. Limiting speed (n G) "5100.0000"
5. Reference speed (n ϑr) "3400.0000"
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NK, light series
