NK60/25-F-XL INA

All dimensions

1. Inner (d) MM 60
2. Outer (D) MM 72
3. Width (B) MM 25
4. Inner (d) Inch 2.3622
5. Outer (D) Inch 2.8346
6. Width (B) Inch 0.9843
7. Under roller diameter (F w) mm 60

Suffix description

1. F Machined Window Type Steel Cage
2. XL X-Life

Technical details

1. Availability 150 pcs
2. Brand INA
3. Item number NK60/25-F-XL INA
4. Also known as 0000013500000
   NK60/25-F

5. EAN 4054369079210
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.185

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 90000
2. Radial Dynamic Load Rating Cr (N) 47500
3. Limiting speed (n G) 7700
4. Reference speed (n ϑr) 4800
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearing NK..-F-XL, single row, no inner ring, outer ring with 2 bords
