NK43/30-XL INA

All dimensions

1. Inner (d) MM 43,00
2. Outer (D) MM 53,00
3. Width (B) MM 30,00
4. Inner (d) Inch 1.6929
5. Outer (D) Inch 2.0866
6. Width (B) Inch 1.1811
7. Under roller diameter (F w) mm 43,00

Suffix description

1. XL X-Life

Technical details

1. Availability 27 pcs
2. Brand INA
3. Item number NK43/30-XL INA
4. Also known as 0507543350000
   NK43/30
   RNA435330
   TAF435330

5. EAN 4012802701470
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.133

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 85000
2. Radial Dynamic Load Rating Cr (N) 45500
3. Basic static load rating, radial (C 0r) "85000.0000"
4. Limiting speed (n G) "10700.0000"
5. Reference speed (n ϑr) "6300.0000"
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NK, light series
