NK37/20-XL INA

All dimensions

1. Inner (d) MM 37
2. Outer (D) MM 47
3. Width (B) MM 20
4. Inner (d) Inch 1.4567
5. Outer (D) Inch 1.8504
6. Width (B) Inch 0.7874
7. Under roller diameter (F w) mm 37

Suffix description

1. XL X-Life

Technical details

1. Availability 314 pcs
2. Brand INA
3. Item number NK37/20-XL INA
4. Also known as 0507542460000
   NB374720
   NK37/20
   RNA374720
   TAF374720

5. EAN 4012802701548
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.077

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 43500
2. Radial Dynamic Load Rating Cr (N) 28000
3. Limiting speed (n G) 12300
4. Reference speed (n ϑr) 7400
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NK, light series
