NK28/30-XL INA

All dimensions

1. Inner (d) MM 28,00
2. Outer (D) MM 37,00
3. Width (B) MM 30,00
4. Inner (d) Inch 1.1024
5. Outer (D) Inch 1.4567
6. Width (B) Inch 1.1811
7. Under roller diameter (F w) mm 28,00

Suffix description

1. XL X-Life

Technical details

1. Availability 53 pcs
2. Brand INA
3. Item number NK28/30-XL INA
4. Also known as 0507541300000
   NK28/30
   RNA283730
   TAF283730

5. EAN 4012802701340
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.078

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 57000
2. Radial Dynamic Load Rating Cr (N) 37000
3. Basic static load rating, radial (C 0r) "57000.0000"
4. Limiting speed (n G) "15800.0000"
5. Reference speed (n ϑr) "9000.0000"
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NK, light series
