NK28/20-XL INA

All dimensions

1. Inner (d) MM 28
2. Outer (D) MM 37
3. Width (B) MM 20
4. Inner (d) Inch 1.1024
5. Outer (D) Inch 1.4567
6. Width (B) Inch 0.7874
7. Under roller diameter (F w) mm 28

Suffix description

1. XL X-Life

Technical details

1. Availability 43 pcs
2. Brand INA
3. Item number NK28/20-XL INA
4. Also known as 0507541220000
   NB283720
   NK28/20
   RNA283720
   TAF283720

5. EAN 4012802701333
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.052

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 34000
2. Radial Dynamic Load Rating Cr (N) 24800
3. Limiting speed (n G) 15800
4. Reference speed (n ϑr) 9300
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NK, light series

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
