NK25/20-XL INA

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 33
3. Width (B) MM 20
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 1.2992
6. Width (B) Inch 0.7874
7. Under roller diameter (F w) mm 25

Suffix description

1. XL X-Life

Technical details

1. Availability 140 pcs
2. Brand INA
3. Item number NK25/20-XL INA
4. Also known as 0507540920000
   NB253320
   NK25/20
   RNA253320
   TAF253320

5. EAN 4012802219470
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.042

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 30500
2. Radial Dynamic Load Rating Cr (N) 21300
3. Limiting speed (n G) 17800
4. Reference speed (n ϑr) 10400
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NK, light series
