NK25/16-XL INA

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 33
3. Width (B) MM 16
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 1.2992
6. Width (B) Inch 0.6299
7. Under roller diameter (F w) mm 25

Suffix description

1. XL X-Life

Technical details

1. Availability 41 pcs
2. Brand INA
3. Item number NK25/16-XL INA
4. Also known as 0507540840000
   NB253316
   NK25/16
   RNA253316
   TAF253316

5. EAN 4012802701302
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.033

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 22400
2. Radial Dynamic Load Rating Cr (N) 16800
3. Limiting speed (n G) 17800
4. Reference speed (n ϑr) 10700
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NK, light series
