NK10/12-TV-XL INA

€ 6,90 ex VAT
€ 8,35 in VAT
€ 8,35 in VAT
€ 6,90 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

NK10/12-TV-XL INA

Needle Roller and Cage Assembly

Stock
56 pcs in stock and ready for shipment
Brand INA
Article number NK10/12-TV-XL INA
Inside diameter 10mm
Outside diameter 17mm
Width 12mm
Product description
Read more Show less
Help with this product

Downloads and links

Similar to: NK10/12-TV-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 10
  2. Outer (D) MM 17
  3. Width (B) MM 12
  4. Inner (d) Inch 0.3937
  5. Outer (D) Inch 0.6693
  6. Width (B) Inch 0.4724
  7. Under roller diameter (F w) mm 10

Suffix description

  1. TV Polyamide Cage
  2. XL X-Life

Technical details

  1. Availability 56 pcs
  2. Brand INA
  3. Item number NK10/12-TV-XL INA
  4. Also known as 0507532900000
    NK10/12-TV
    NK1012TN
  5. EAN 4012802733365
  6. Category Needle Roller and Cage Assembly

Weight and Dimensions

  1. Weight (kg) 0.01

Product Properties

  1. Seal No Seal

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 5500
  2. Radial Dynamic Load Rating Cr (N) 5300
  3. Limiting speed (n G) 29500
  4. Reference speed (n ϑr) 29000
  5. ECLASS number 23-05-09-07
  6. ECLASS2 number 23-05-09-07
  7. Medias description Needle roller bearings NK, light series

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
