NJG2319CV Rollway

All dimensions

1. Inner (d) MM 95
2. Outer (D) MM 200
3. Width (B) MM 67
4. Inner (d) Inch 3.7402
5. Outer (D) Inch 7.874
6. Width (B) Inch 2.6378

Suffix description

1. C Deviating Or Modified Internal Design With Same Boundary Dimensions
2. V Full Complement Of Rollers (Without Cage)

Technical details

1. Availability 15 pcs
2. Brand Rollway
3. Item number NJG2319CV Rollway
4. Also known as SL192319-A

5. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 10.27

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type FC - Full Complement, No Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
