NJ313ETC4-VM NSK

All dimensions

1. Inner (d) MM 65
2. Outer (D) MM 140
3. Width (B) MM 33
4. Inner (d) Inch 2.5591
5. Outer (D) Inch 5.5118
6. Width (B) Inch 1.2992

Suffix description

1. E High Capacity Design
2. T Glass Fibre Reinforced Polyamide Cage
3. C4 Bearing Internal Clearance Greater Than C3
4. VM Inner Ring With Crowned Raceway For Increased Permissible Misalignment

Technical details

1. Availability 5 pcs
2. Brand NSK
3. Item number NJ313ETC4-VM NSK
4. Also known as NJ313ECP/C4VQ015
   NJ313-E-TVP2-QP51-C4

5. EAN 00192661075227
6. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 2.24

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision A0 - Inner Ring Crowned Raceway
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
