NJ2330-E-XL-MCA-C4 FAG

All dimensions

1. Inner (d) MM 150
2. Outer (D) MM 320
3. Width (B) MM 108
4. Inner (d) Inch 5.9055
5. Outer (D) Inch 12.5984
6. Width (B) Inch 4.252

Suffix description

1. E Increased Load Capacity
2. XL X-Life
3. MCA Solid Brass Cage, Single-Piece, Guided On Outer Ring
4. C4 Bearing Internal Clearance Greater Than C3

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number NJ2330-E-XL-MCA-C4 FAG
4. Also known as 0954656180040
   NJ2330-E-MCA-C4

5. EAN 4054372882869
6. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 44.7

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type MA - Brass Cage, Centered on Outer Ring
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Downloads and links

1. Download datasheet Download datasheet
2. Link to Manufacturer Link to Manufacturer
