NAO20X35X17 INA

All dimensions

1. Inner (d) MM 20,00
2. Outer (D) MM 35,00
3. Width (B) MM 17,00
4. Inner (d) Inch 0.7874
5. Outer (D) Inch 1.3780
6. Width (B) Inch 0.6693
7. Width (b) mm 17,00

Suffix description

1. -4-6 Micron - Needle Sort

Technical details

1. Availability 39 pcs
2. Brand INA
3. Item number NAO20X35X17 INA
4. Also known as 0000106500000

5. EAN 4012801175814
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.076

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 26000
2. Radial Dynamic Load Rating Cr (N) 14900
3. Basic static load rating, radial (C 0r) "26000.0000"
4. Limiting speed (n G) "18100.0000"
5. Limiting speed for grease lubrication (n G Grease) "10900.0000"
6. Reference speed (n ϑr) "10000.0000"
7. ECLASS number 23-05-09-07
8. ECLASS2 number 23-05-09-07
9. Medias description Radial roller bearing NAO
