NAO12X24X13 INA

All dimensions

1. Inner (d) MM 12
2. Outer (D) MM 24
3. Width (B) MM 13
4. Inner (d) Inch 0.4724
5. Outer (D) Inch 0.9449
6. Width (B) Inch 0.5118
7. Width (b) mm 13

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number NAO12X24X13 INA
4. Also known as 0001432510000
   NAF122413

5. EAN 4012802716900
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.03

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 11800
2. Radial Dynamic Load Rating Cr (N) 8900
3. Limiting speed (n G) 23600
4. Limiting speed for grease lubrication (n G Grease) 14100
5. Reference speed (n ϑr) 15000
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Radial roller bearing NAO
