NA4924-XL-C3 INA

All dimensions

1. Inner (d) MM 120,00
2. Outer (D) MM 165,00
3. Width (B) MM 45,00
4. Inner (d) Inch 4.7244
5. Outer (D) Inch 6.4961
6. Width (B) Inch 1.7717
7. Width (b) mm 45,00

Suffix description

1. XL X-Life
2. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 7 pcs
2. Brand INA
3. Item number NA4924-XL-C3 INA
4. Also known as 0506616710030
   NA4924-C3

5. EAN 4047643205429
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 2.883

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) "390000.0000"
2. Limiting speed (n G) "3400.0000"
3. Limiting speed for grease lubrication (n G Grease) "2040.0000"
4. Reference speed (n ϑr) "2160.0000"
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
