NA4915-XL INA

All dimensions

1. Inner (d) MM 75,00
2. Outer (D) MM 105,00
3. Width (B) MM 30,00
4. Inner (d) Inch 2.9528
5. Outer (D) Inch 4.1339
6. Width (B) Inch 1.1811
7. Width (b) mm 30,00

Suffix description

1. XL X-Life

Technical details

1. Availability 3 pcs
2. Brand INA
3. Item number NA4915-XL INA
4. Also known as 0506615900000
   NA4915
   NU4915B

5. EAN 4012802508611
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.775

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 162000
2. Radial Dynamic Load Rating Cr (N) 97000
3. Basic static load rating, radial (C 0r) "162000.0000"
4. Limiting speed (n G) "5400.0000"
5. Limiting speed for grease lubrication (n G Grease) "3200.0000"
6. Reference speed (n ϑr) "3100.0000"
7. ECLASS number 23-05-09-07
8. ECLASS2 number 23-05-09-07
9. Medias description Radial roller bearing NA..-XL

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
