NA4832-XL-C3-2S-L271 INA

All dimensions

1. Inner (d) MM 160,00
2. Outer (D) MM 200,00
3. Width (B) MM 40,00
4. Inner (d) Inch 6.2992
5. Outer (D) Inch 7.8740
6. Width (B) Inch 1.5748
7. Width (b) mm 40,00

Suffix description

1. XL X-Life
2. C3 Internal Clearance Larger Than Normal
3. 2S If Two Or More Bearings Are Located Adjacent To Each Other In A Planet (2, 3 Or 4 Bearings), These Must Be Ordered Using The Suffix 2S, 3S Or 4S So That They Are Sorted Together
4. L271 Anti Wear Protection Grease

Technical details

1. Availability 2 pcs on 9 May
2. Brand INA
3. Item number NA4832-XL-C3-2S-L271 INA
4. Also known as 0507685145100
   NA4832-C3-2S-L271

5. EAN 4054363037544
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 2.89

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) "435000.0000"
2. Limiting speed (n G) "2700.0000"
3. Reference speed (n ϑr) "1650.0000"
4. ECLASS number 23-05-09-07
5. ECLASS2 number 23-05-09-07

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
