NA4826-XL INA

All dimensions

1. Inner (d) MM 130
2. Outer (D) MM 165
3. Width (B) MM 35
4. Inner (d) Inch 5.1181
5. Outer (D) Inch 6.4961
6. Width (B) Inch 1.378
7. Width (b) mm 35

Suffix description

1. XL X-Life

Technical details

1. Availability 10 pcs
2. Brand INA
3. Item number NA4826-XL INA
4. Also known as 0507684840000
   NA4826

5. EAN 4047643115582
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 1.81

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 310000
2. Radial Dynamic Load Rating Cr (N) 134000
3. Limiting speed (n G) 3250
4. Reference speed (n ϑr) 1930
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearing NA..-XL, single row, with inner ring, outer ring with 2 bords
