N1016BTKRCC1P4 NSK

All dimensions

1. Inner (d) MM 80
2. Outer (D) MM 125
3. Width (B) MM 22
4. Inner (d) Inch 3.1496
5. Outer (D) Inch 4.9213
6. Width (B) Inch 0.8661

Suffix description

1. B Internal Design Modification
2. T Glass Fibre Reinforced Polyamide Cage
3. KR Ultra Precision Tapered Bore (1:12)
4. CC1 For Non-Interchangeable Cylindrical Roller Bearings, Clearance Less Than CC2
5. P4 Dimensional & Running Accuracy To Iso Tolerance Class 4 (More Accurate Than P5)-Abec7

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number N1016BTKRCC1P4 NSK
4. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.89

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play C1 Internal Play (Less than C2)
6. Precision P4 Precision (Higher than P5)
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
