N1011-D-K-PVPA1-SP-XL-R10-20 FAG

All dimensions

1. Inner (d) MM 55
2. Outer (D) MM 90
3. Width (B) MM 18
4. Inner (d) Inch 2.1654
5. Outer (D) Inch 3.5433
6. Width (B) Inch 0.7087

Suffix description

1. D Bearings With A Modified Internal Construction And The Suffix D Do Not Have A Lubrication Hole Or Lubrication Groove As Standard
2. K Tapered Bore, Taper 1:12
3. PVPA1 PEEK Cage Guided On One Side
4. SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1
5. XL X-Life
6. R10-20 Radial Clearance In μm

Technical details

1. Availability 1 pc
2. Brand FAG
3. Item number N1011-D-K-PVPA1-SP-XL-R10-20 FAG
4. Also known as 0974505614001

5. EAN 4064328008007
6. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.32

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Seal No Seal
3. Cage Type PH - PEEK Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision SP - Precision Higher than P4S
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
