MA5217EXC3245 Rexnord

All dimensions

1. Inner (d) MM 85
2. Outer (D) MM 150
3. Width (B) MM 49,21
4. Inner (d) Inch 3.3465
5. Outer (D) Inch 5.9055
6. Width (B) Inch 1.9375

Suffix description

1. E Double Rib Outer Ring
2. X Segmented Retainer
3. C3245 Internal Clearance 0.0032" To 0.0045"

Technical details

1. Availability 0 pcs
2. Brand Rexnord
3. Item number MA5217EXC3245 Rexnord
4. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 3.496

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Special Internal Clearance
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
