M1313EAHX Bower

All dimensions

1. Outer (D) MM 140
2. Width (B) MM 33
3. Inner (d) Inch 3.294

Suffix description

1. E Two Ribbed Outer Ring
2. A Oversized O.D. For Heavy Press Fit in Standard Housing Bore
3. H Blind Dowel Hole in Outer Ring O.D
4. X Segmented Retainer

Technical details

1. Availability 0 pcs
2. Brand Bower
3. Item number M1313EAHX Bower
4. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 1.975

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
