LSL192318-TB-XL INA

All dimensions

1. Inner (d) MM 90
2. Outer (D) MM 190
3. Width (B) MM 64
4. Inner (d) Inch 3.5433
5. Outer (D) Inch 7.4803
6. Width (B) Inch 2.5197

Suffix description

1. TB In The Case Of Bearings Of TB Design, The Axial Load Carrying Capacity Of Cylindrical Roller Bearings Was Significantly Improved With The Aid Of New Calculation And Manufacturing Methods. Optimum Contact Conditions Between The Roller And Rib Are Ensured By Means Of A Special Curvature Of The Roller End Faces. As A Result, The Axial Contact Pressures On The Rib Are Significantly Minimised And A Lubricant Film Capable Of Supporting Higher Loads Is Formed. Under Normal Operating Conditions, Wear And Fatigue At The Rib Contact Running And Roller End Faces Is Completely Eliminated. In Addition, Axial Frictional Torque Is Reduced By Up To 50%. The Bearing Temperature During Operation Is Therefore Significantly Lower
2. XL X-Life

Technical details

1. Availability 4 pcs
2. Brand INA
3. Item number LSL192318-TB-XL INA
4. Also known as LSL192318-TB
   NJ2318-E-MPAX-ILR
   NJ2318-E-XL-MPAX-ILR

5. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 8.6

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 610000
2. Radial Dynamic Load Rating Cr (N) 590000
3. ECLASS number 23-05-09-01
4. ECLASS2 number 23-05-09-01
5. Medias description Cylindrical roller bearing, LSL1923 with disc cage, single row, semi-locating bearing, 2 ribs on outer ring, 1 rib on inner ring, 1 disc cage, type LSL1923
