LSL192316-A-C4 INA

All dimensions

1. Inner (d) MM 80,00
2. Outer (D) MM 170,00
3. Width (B) MM 58,00
4. Inner (d) Inch 3.1496
5. Outer (D) Inch 6.6929
6. Width (B) Inch 2.2835

Suffix description

1. A The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
2. C4 Bearing Internal Clearance Greater Than C3

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number LSL192316-A-C4 INA
4. Also known as 0071615300040
   NJ2316-E-MPAX-ILR-C4
   NJ2316-E-XL-MPAX-ILR-C4

5. EAN 4054363034079
6. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 6.1

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. ECLASS number 23-05-09-01
2. ECLASS2 number 23-05-09-01
