LS75100 INA

All dimensions

1. Inner (d) MM 75
2. Outer (D) MM 100
3. Width (B) MM 5,75
4. Inner (d) Inch 2.9528
5. Outer (D) Inch 3.937
6. Width (B) Inch 0.2264
7. Outside diameter track washer (D) mm 100
8. Width (b) mm 5,75
9. Chamfer width (a min) mm 1,5

Technical details

1. Availability 134 pcs
2. Brand INA
3. Item number LS75100 INA
4. Also known as 0000551820000

5. EAN 4012802713954
6. Category Washer for Needle Roller Thrust Bearings

Weight and Dimensions

1. Weight (kg) 0.142

Data from Schaeffler (medias)

1. Chamfer angle 45
2. ECLASS number 23-05-91-90
3. ECLASS2 number 23-05-91-90
4. Medias description Bearing washers, suitable for AXK and K811
