LS14.1/2 FAG

All dimensions

1. Inner (d) MM 47,63
2. Outer (D) MM 101,6
3. Width (B) MM 20,64
4. Inner (d) Inch 1.875
5. Outer (D) Inch 4
6. Width (B) Inch 0.8125

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number LS14.1/2 FAG
4. Also known as LJ1.7/8
   PA15
   RLS15

5. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.715

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
