LNNU4930-SP-C3 FAG

All dimensions

1. Inner (d) MM 150,00
2. Outer (D) MM 168,50
3. Width (B) MM 60,00
4. Inner (d) Inch 5.9055
5. Outer (D) Inch 6.6339
6. Width (B) Inch 2.3622

Suffix description

1. SP Special Precision Class For Machine Tool Bearings: Dimensional Accuracy Approximately To P5, Running Accuracy Approximately To P4
2. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 4 pcs
2. Brand FAG
3. Item number LNNU4930-SP-C3 FAG
4. Also known as 0384710270030

5. EAN 4012802199246
6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 2.08

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision SP - Precision Higher than P4S
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. ECLASS number 23-05-91-90
2. ECLASS2 number 23-05-91-90
