LM8LUU Samick

All dimensions

1. Inner (d) MM 8
2. Outer (D) MM 15
3. Width (B) MM 45
4. Inner (d) Inch 0.315
5. Outer (D) Inch 0.5906
6. Width (B) Inch 1.7717

Suffix description

1. L Extra Long
2. UU The Two Seal Types Incorporate Seals With Superior Dust Protection Performance At Both Ends Of The External Cylinder For Preventing Intrusion Of Foreign Matter. The Maximum Allowable Temperature For Seals Is 120°C

Technical details

1. Availability 5 pcs
2. Brand Samick
3. Item number LM8LUU Samick
4. Category Linear Ball Bearing

Weight and Dimensions

1. Weight (kg) 0.0031

Product Properties

1. Seal No Seal
