LM78349/LM78310A ZKL

Single-row tapered roller bearing

Stock
not in stock
Brand ZKL
Article number LM78349/LM78310A ZKL
Inside diameter 34,99mm
Outside diameter 61,97mm
Width 18mm
Product description

The LM78349/LM78310A ZKL is a single-row tapered roller bearing. This bearing type gets its name from the tapered rollers between the inner and outer rings. The raceways are conical. This design allows these versatile bearings to accommodate combined loads. They support high radial and axial loads (in one direction). The greater the contact angle, the greater the axial load capacity.

The LM78349/LM78310A ZKL is easy to (dis)assemble as it is a combination of a cup and a cone. The cone unit consists of an inner ring with cage and roller set. The cup is the outer ring. Single-row tapered roller bearings have an open design. Because of the internal construction, they must be mounted in mirror-image arrangement together with a second tapered roller bearing. Paired bearing sets can also be applied in X, O, or tandem arrangements.

Help with this product

Similar to: LM78349/LM78310A ZKL

Product
Dimensions/Properties
Stock
Price ex VAT
LM78349/LM78310A Timken
LM78349/LM78310A Timken
Guaranteed same day shipment on orders placed before 18:00h (CET)
43,52 ex VAT
  • Inside diameter 34,99mm
  • Outside diameter 61,97mm
  • Width 18mm
LM78349/LM78310A Timken
Guaranteed same day shipment on orders placed before 18:00h (CET)

50 pcs
43,52 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 34,99
  2. Outer (D) MM 61,97
  3. Width (B) MM 18
  4. Inner (d) Inch 1.3775
  5. Outer (D) Inch 2.4399
  6. Width (B) Inch 0.7087

Suffix description

  1. A Single Row Tapered Roller Bearing With Higher Load Rating And Higher Limiting Speed

Technical details

  1. Availability 0 pcs
  2. Brand ZKL
  3. Item number LM78349/LM78310A ZKL
  4. Also known as LM78349/310A
  5. Category Tapered Roller Bearing Single Row

Weight and Dimensions

  1. Weight (kg) 0.19

Product Properties

  1. Precision Standard Precision
