LASE45-XL INA

Name: LASE45-XL INA
Brand: INA

€ 92,33 ex VAT

€ 111,72 incl. VAT

€ 92,33 ex VAT

	Guaranteed same day shipment on orders placed before 17.00h (CEST)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

LASE45-XL INA

Housing unit

Stock	26 pcs in stock and ready for shipment
Brand	INA
Article number	LASE45-XL INA
Inside diameter	45,00mm
Outside diameter	192,00mm
Width	107,00mm

Product description

The LASE45-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Email us at: help@247industries.com Response within 24h

Downloads and links

Similar to: LASE45-XL INA

Loading similair products

Product specifications

Inside diameter 45,00mm
Outside diameter 192,00mm
Width 107,00mm

All dimensions

Inner (d) MM 45,00
Outer (D) MM 192,00
Width (B) MM 107,00
Inner (d) Inch 1.7717
Outer (D) Inch 7.5591
Width (B) Inch 4.2126
Length total (L) mm 192,00
Height (H 2) mm 107,00

Suffix description

XL X-Life

Technical details

Availability 26 pcs
Brand INA
Item number LASE45-XL INA
Also known as 0008576370000
LASE45
EAN 4012802798272
Category Housing and Bearing (assembly)

Weight and Dimensions

Weight (kg) 2.31

Product Properties

Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment

Data from Schaeffler (medias)

ECLASS number 23-05-16-01
ECLASS2 number 23-05-16-01
Medias description Plummer block housing units LASE, cast iron housing, radial insert ball bearing with eccentric locking collar, L seals
