L10SA500T.PL4 FAG

All dimensions

1. Inner (d) MM 127
2. Outer (D) MM 146,05
3. Width (B) MM 9,525
4. Inner (d) Inch 5
5. Outer (D) Inch 5.75
6. Width (B) Inch 0.375

Suffix description

1. T Molded Snap-Type Cage Of Glass Fibre Reinforced Polyamide
2. PL4 Reduced Tolerance And Radial Clearance (FAG), Higher Precision Than PL3

Technical details

1. Availability 78 pcs
2. Brand FAG
3. Item number L10SA500T.PL4 FAG
4. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.224

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision P4 Precision (Higher than P5)
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
