KZK16X22X12/0-7 INA

All dimensions

1. Inner (d) MM 16
2. Outer (D) MM 22
3. Width (B) MM 12
4. Inner (d) Inch 0.6299
5. Outer (D) Inch 0.8661
6. Width (B) Inch 0.4724
7. Outside diameter of needle roller complement (E w) mm 22
8. Width (B c) mm 12

Suffix description

1. /0-7 Micron - Needle Sort

Technical details

1. Availability 50 pcs on Tue 21 Apr
2. Brand INA
3. Item number KZK16X22X12/0-7 INA
4. Also known as 0014765136063

5. EAN 4012802725674
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.02

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 11900
2. Radial Dynamic Load Rating Cr (N) 11000
3. Limiting speed (n G) 22900
4. ECLASS number 23-05-09-04
5. ECLASS2 number 23-05-09-04
6. Medias description Needle roller cage assembly KZK, single row, similar KZK, crank pin bearing

Downloads and links

1. Download datasheet Download datasheet
2. Link to Manufacturer Link to Manufacturer
