KWVE25-B-EC-V1-G3 INA

All dimensions

1. Inner (d) MM 23
2. Outer (D) MM 73
3. Width (B) MM 58,2
4. Inner (d) Inch 0.9055
5. Outer (D) Inch 2.874
6. Width (B) Inch 2.2913
7. Width carriage (B) mm 73
8. Overall length carriage (L) mm 58,2

Suffix description

1. B Version
2. EC Expanded Design, Short Carriage (Carriage Without Screw Threads)
3. V1 Slight Preload
4. G3 Precision Class 3

Technical details

1. Availability 42 pcs
2. Brand INA
3. Item number KWVE25-B-EC-V1-G3 INA
4. Also known as 0116944590240
   KWVE25-B-EC-G3-V1

5. EAN 4054366320483
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 0.4

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 12500
2. Static load rating (C 0) 22200
3. Static moment rating about X axis (M 0x) 305
4. Static moment rating about Y axis (M 0y) 155
5. Static moment rating about Z axis (M 0z) 155
6. ECLASS number 23-30-04-90
7. ECLASS2 number 23-30-04-90
8. Medias description Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row
