KWVE15-B-E-V1-G3 INA

All dimensions

1. Inner (d) MM 15
2. Outer (D) MM 47
3. Width (B) MM 61,2
4. Inner (d) Inch 0.5906
5. Outer (D) Inch 1.8504
6. Width (B) Inch 2.4094
7. Width carriage (B) mm 52
8. Overall length carriage (L) mm 61,2

Suffix description

1. B Standard Carriage, Four-Row, Full Complement Ball Set
2. E Expanded Design (Carriage Without Screw Threads)
3. V1 Slight Preload
4. G3 Precision Class 3

Technical details

1. Availability 10 pcs
2. Brand INA
3. Item number KWVE15-B-E-V1-G3 INA
4. Also known as 0339353510240
   KWVE15-B-E-G3-V1

5. EAN 4054362962809
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 0.2

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 7200
2. Static load rating (C 0) 14500
3. Static moment rating about X axis (M 0x) 150
4. Static moment rating about Y axis (M 0y) 100
5. Static moment rating about Z axis (M 0z) 100
