KUVS13-B INA

All dimensions

1. Inner (d) MM 42
2. Outer (D) MM 75
3. Width (B) MM 19
4. Inner (d) Inch 1.6535
5. Outer (D) Inch 2.9528
6. Width (B) Inch 0.748
7. Width rail (b) mm 42
8. Width system (B) mm 75
9. Length linear recirculating ball bearing units (L) mm 71
10. Height rail (h) mm 18
11. Max. length rail (l max) mm 2940

Suffix description

1. B Standard Carriage, Four-Row, Full Complement Ball Set

Technical details

1. Availability 22 pcs
2. Brand INA
3. Item number KUVS13-B INA
4. Also known as 0075636800000

5. EAN 4054362930631
6. Category Linear Ball Bearing Unit

Weight and Dimensions

1. Weight (kg) 0.085

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Load capacity dyn. C (C) 13500
2. Load capacity dyn C0 (C 0) 26000
3. ECLASS number 23-30-04-90
4. ECLASS2 number 23-30-04-90
