KN50-B INA

All dimensions

1. Inner (d) MM 50
2. Outer (D) MM 75
3. Width (B) MM 100
4. Inner (d) Inch 1.9685
5. Outer (D) Inch 2.9528
6. Width (B) Inch 3.937
7. Length (L) mm 100

Suffix description

1. B Guideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B

Technical details

1. Availability 13 pcs
2. Brand INA
3. Item number KN50-B INA
4. Also known as 0296807000000
   KN50100
   LBCD50A
   LMES50
   R0670-050-00
   SPM50
   TK50

5. EAN 4047643206709
6. Category Linear Ball Bearing

Weight and Dimensions

1. Weight (kg) 0.44

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Load capacity dyn. (C min) 9300
2. Load capacity stat. (C 0 min) 6500
3. Load capacity stat. (C 0 max) 8300
4. ECLASS number 23-30-03-01
5. ECLASS2 number 23-30-03-01
6. Medias description Linear ball bearings KN..-B, Lightweight range, closed design, with relubrication facility, adjustable angle

Downloads and links

1. Link to manufacturer Link to manufacturer
