KD045XP0K Kaydon

All dimensions

1. Inner (d) MM 114,3
2. Outer (D) MM 139,7
3. Width (B) MM 12,7
4. Inner (d) Inch 4.5
5. Outer (D) Inch 5.5
6. Width (B) Inch 0.5

Suffix description

1. X Four-Point Contact
2. P Standard Formed Ring “Snap-Over” Type (Material—Brass Or Non-Metallic Composite)
3. O KAYDON Precision Class 1 Per ABEC 1F
4. K 0000 to .0005 Preload

Technical details

1. Availability 1 pc
2. Brand Kaydon
3. Item number KD045XP0K Kaydon
4. Category Four Point Contact Ball Bearing

Weight and Dimensions

1. Weight (kg) 0.362

Product Properties

1. Seal No Seal
2. Cage Type S - Steel or Standard Cage
3. External Modification No External Modification
4. Radial Internal Play Cn Normal Internal Play
5. Precision Standard Precision
6. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
7. Split Inner ring / Outer ring Standard
