KC040BROK Kaydon

All dimensions

1. Inner (d) MM 101,6
2. Outer (D) MM 120,65
3. Width (B) MM 9,525
4. Inner (d) Inch 4
5. Outer (D) Inch 4.75
6. Width (B) Inch 0.375

Suffix description

1. B Angular Contact Pair - Duplexed Back To Back
2. R Standard Formed Ring, Circular Pocket (Material Brass Or Non-Metallic Composite)
3. O Kaydon Precision Class 1 Per Abec1F
4. K 0000 To .0005 Preload

Technical details

1. Availability 13 pcs
2. Brand Kaydon
3. Item number KC040BROK Kaydon
4. Category Angular Contact Ball Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.378

Product Properties

1. Seal No Seal
2. Cage Type M - Brass Cage
3. Precision ABEC.1 Tolerances
4. Contact Angle Standard Contact Angle
5. Pairing DB - O-arrangement, 2
6. Axial Internal Clearance / Preload GA - Light Preload
7. Lubrication Standard Lubrication
