K81122-TV/0-8 INA

All dimensions

1. Inner (d) MM 110,00
2. Outer (D) MM 145,00
3. Width (B) MM 11,00
4. Inner (d) Inch 4.3307
5. Outer (D) Inch 5.7087
6. Width (B) Inch 0.4331
7. Cage outer diameter (D c) mm 145,00

Suffix description

1. TV Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding
2. /0-8 Micron - Needle Sort

Technical details

1. Availability 1 pc on 27 May
2. Brand INA
3. Item number K81122-TV/0-8 INA
4. Also known as 0011972669064

5. EAN 4012802046557
6. Category Cylindrical Roller Bearing with Cage (assembly)

Weight and Dimensions

1. Weight (kg) 0.346

Product Properties

1. Cage Type P - Plastic Molded Cage
2. Precision Standard Precision

Data from Schaeffler (medias)

1. Basic dynamic load rating, axial (C a) "207000.0000"
2. Axial Static Load Rating C0a (N) 700000
3. Basic static load rating, axial (C 0a) "700000.0000"
4. Axial Dynamic Load Rating Ca (N) 207000
5. Limiting speed (n G) "2260.0000"
6. Reference speed (n ϑr) "850.0000"
7. ECLASS number 23-05-11-90
8. ECLASS2 number 23-05-11-90
9. Medias description Axial cylindrical roller and cage assembly K811, single direction, suitable for combination with axial bearing washers
