K70X78X23-TV/0-7 INA

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 78
3. Width (B) MM 23
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 3.0709
6. Width (B) Inch 0.9055
7. Outside diameter of needle roller complement (E w) mm 78
8. Width (B c) mm 23

Suffix description

1. TV Polyamide Cage
2. /0-7 Micron - Needle Sort

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number K70X78X23-TV/0-7 INA
4. Also known as 0001712556063

5. EAN 4047643175609
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.072

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 103000
2. Radial Dynamic Load Rating Cr (N) 48500
3. Limiting speed (n G) 6600
4. Reference speed (n ϑr) 4000
5. ECLASS number 23-05-09-04
6. ECLASS2 number 23-05-09-04
7. Medias description Needle roller cage assembly K..-TV, single row
