JU050XP0 Kaydon

All dimensions

1. Inner (d) MM 127,00
2. Outer (D) MM 146,05
3. Width (B) MM 12,70
4. Inner (d) Inch 5.0000
5. Outer (D) Inch 5.7500
6. Width (B) Inch 0.5000

Suffix description

1. X Four-Point Contact
2. P Standard Formed Ring “Snap-Over” Type (Material—Brass Or Non-Metallic Composite)
3. O KAYDON Precision Class 1 Per ABEC 1F

Technical details

1. Availability 1 pc
2. Brand Kaydon
3. Item number JU050XP0 Kaydon
4. Also known as CSXU050 2RS
   FPXU500-2RS1
   JSU050XPO
   L18SG500.2RSD
   NBX12712DD

5. Category Four Point Contact Ball Bearing

Weight and Dimensions

1. Weight (kg) 0.29

Product Properties

1. Seal 2RS - Rubber Seal on Two Sides
2. Cage Type M - Brass Cage
3. External Modification No External Modification
4. Radial Internal Play Cn Normal Internal Play
5. Precision ABEC.1 Tolerances
6. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
7. Split Inner ring / Outer ring Standard
