JK0S070-A FAG

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 110
3. Width (B) MM 27
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 4.3307
6. Width (B) Inch 1.063
7. Width inner ring (B) mm 27

Suffix description

1. A Internal Design Modification

Technical details

1. Availability 78 pcs
2. Brand FAG
3. Item number JK0S070-A FAG
4. Also known as 0167316030000

5. EAN 4012801155205
6. Category Tapered Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.9

Product Properties

1. Precision Standard Precision

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 159000
2. Radial Dynamic Load Rating Cr (N) 104000
3. Limiting speed (n G) 2900
4. ECLASS number 23-05-09-10
5. ECLASS2 number 23-05-09-10
6. Medias description Tapered roller bearings JK0S, integral tapered roller bearings, lip seal on one side, diameter series 0
