JK0S050 FAG

All dimensions

1. Inner (d) MM 50
2. Outer (D) MM 80
3. Width (B) MM 22
4. Inner (d) Inch 1.9685
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.8661
7. Width inner ring (B) mm 22

Suffix description

1. >A

Technical details

1. Availability 89 pcs
2. Brand FAG
3. Item number JK0S050 FAG
4. Also known as 0167315900000
   0956420640000
   BT1B332892
   JKOS050

5. EAN 4012801042291
6. Category Tapered Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.408

Product Properties

1. Precision Standard Precision

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 93000
2. Radial Dynamic Load Rating Cr (N) 64000
3. Limiting speed (n G) 4050
4. ECLASS number 23-05-09-10
5. ECLASS2 number 23-05-09-10
6. Medias description Tapered roller bearings JK0S, integral tapered roller bearings, lip seal on one side, diameter series 0
